| Varenummer | A101VW01 V0 |
| Mærke | AUO |
| Størrelse | 10.1 |
| Ansøgning | DPF |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | AUO |
| panel model | A101VW01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 219.6×131.76 mm |
| omrids | 235×145.9×6.2 mm |
| overflade | Antiglare |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 12/18 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 60 pins |
| indgangsspænding | 3.3/8.8/15/-7.0/3.7V (Typ.)(VCC/AVDD/VGH/VGL/VCOM) |
| Ansøgning | DPF |
| A101VW01 V0 | AUO | 10.1 | 800×480 |
| A101VW01 V1 | AUO | 10.1 | 800×480 |
| A101VW01 V3 | AUO | 10.1 | 800×480 |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| DLC1010DZG-T-8 | Other | 10.1 | 1280×800 |
| G101EVN01.3 | AUO | 10.1 | 1280×800 |
| LP101WX1-SLN2 | LG Display | 10.1 | 1280×800 |
| LTL101AL03-W01 | Samsung | 10.1 | 1280×800 |
| A070FW05 V1 | AUO | 7.0 | 480×234 |
| A070SN01 V3 | AUO | 7.0 | 800×600 |
| A085FW01 V5 | AUO | 8.5 | 480×234 |
| A101VW01 V3 | AUO | 10.1 | 800×480 |
| AT080TN52 | Innolux | 8.0 | 800×600 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA104XA01CW | CPT | 10.4 | 1024×768 |
| EJ080NA-04C | Innolux | 8.0 | 1024×768 |
| LB070WV1-TD08 | LG Display | 7.0 | 800×480 |
| LTA070B0C0A | TOSHIBA | 7.0 | 480×234 |
