| Varenummer | B101EW05 V0 |
| Mærke | AUO |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 1300:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | B101EW05 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 216.96×135.6 mm |
| omrids | 241.86×161.6×5.2 mm |
| overflade | Hard coating (3H), Reflection 1.5% (Max.) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 1300:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| B101EAN01.1 | AUO | 10.1 | 1280×800 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101EAN01.3 | AUO | 10.1 | 1280×800 |
| B101EAN01.7 | AUO | 10.1 | 1280×800 |
| B101EVT03.1 | AUO | 10.1 | 1280×800 |
| B101EVT04.0 | AUO | 10.1 | 1280×800 |
| B101EW01 V0 | AUO | 10.1 | 1280×720 |
| B101EW02 V0 | AUO | 10.1 | 1280×720 |
| B101EW05 V0 | AUO | 10.1 | 1280×800 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| EJ080NA-04A | Innolux | 8.0 | 1024×768 |
| HSD101PWW2-A01 | HannStar | 10.1 | 1280×800 |
| HX104X01-212 | HYDIS | 10.4 | 1024×768 |
| LP097X02-SLAA | LG Display | 9.7 | 1024×768 |
| LP101WH4-SLAF | LG Display | 10.1 | 1366×768 |
| LTL070NL02-W02 | Samsung | 7.0 | 1024×600 |
| LTL090CL01-002 | Samsung | 9.0 | 1920×1280 |
| LTL101AL06-W14 | Samsung | 10.1 | 1280×800 |
| LTN070NL01-801 | Samsung | 7.0 | 1024×600 |
| N101ICG-L21 Rev.A1 | Innolux | 10.1 | 1280×800 |
