| Varenummer | A101VW01 V1 |
| Mærke | AUO |
| Størrelse | 10.1 |
| Ansøgning | DPF |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 180 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | A101VW01 V1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 219.6×131.76 mm |
| omrids | 235×145.9×5.4 mm |
| overflade | Antiglare |
| lysstyrke | 180 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 12/18 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S8PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 60 pins |
| indgangsspænding | 3.3/8.8/15/-7.0/3.7V (Typ.)(VCC/AVDD/VGH/VGL/VCOM) |
| Ansøgning | DPF |
| A101VW01 V0 | AUO | 10.1 | 800×480 |
| A101VW01 V1 | AUO | 10.1 | 800×480 |
| A101VW01 V3 | AUO | 10.1 | 800×480 |
| B101EAN01.4 | AUO | 10.1 | 1280×800 |
| B101EW02 V0 | AUO | 10.1 | 1280×720 |
| B101UAN07.2 | AUO | 10.1 | 1200×1920 |
| HSD101PWW1-A00-C40 | HannStar | 10.1 | 1280×800 |
| HSD101PWW1-B00-C11 | HannStar | 10.1 | 1280×800 |
| LP101WS1-TLB3 | LG Display | 10.1 | 1024×576 |
| LTL101AL02-T01 | Samsung | 10.1 | 1280×800 |
| A080SN02 V0 | AUO | 8.0 | 800×600 |
| A101VW01 V3 | AUO | 10.1 | 800×480 |
| AT102TN03 V.1 | Innolux | 10.2 | 800×480 |
| EJ080NA-04C | Innolux | 8.0 | 1024×768 |
| HSD100IFW1-C01 | HannStar | 10.1 | 1024×600 |
| HSD101PFW2-C00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW3-D00 | HannStar | 10.1 | 1024×600 |
| LSA40AT9001 | Innolux | 10.4 | 800×600 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
| TM080SV-04L01 | SANYO | 8.0 | 800×600 |
