| Varenummer | AA070MC01 |
| Mærke | Mitsubishi |
| Størrelse | 7.0 |
| Ansøgning | IA |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 1000 |
| CR | 1000:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | Mitsubishi |
| panel model | AA070MC01 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 152.4×91.44 mm |
| omrids | 169.8×109.7×9.4 mm |
| overflade | Clear, Hard coating (3H) |
| lysstyrke | 1000 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 8-bit), CIE193150% |
| responstid | 12/12 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| AA070MC01 | Mitsubishi | 7.0 | 800×480 |
| AA070MC11 | Mitsubishi | 7.0 | 800×480 |
| AA070ME01 | Mitsubishi | 7.0 | 800×480 |
| AA070ME01-DA1 | Mitsubishi | 7.0 | 800×480 |
| AA078AA01 | Mitsubishi | 7.8 | 800×300 |
| AT070TN07 V.D | Innolux | 7.0 | 480×234 |
| BP070WS1-200 | BOE | 7.0 | 1024×600 |
| LB070WV6-TD08 | LG Display | 7.0 | 800×480 |
| LQ0DAS0749 | SHARP | 7.0 | 600×800 |
| AA070ME01 | Mitsubishi | 7.0 | 800×480 |
| COM50H5125XLC | ORTUSTECH | 5.0 | 320×240 |
| EL320.240.36 | Lumineq | 5.7 | 320×240 |
| KHS038AA1AA-B70R-57-11 | Kyocera | 3.8 | 240×320 |
| LM64C21P | SHARP | 8.0 | 640×480 |
| LQ084V1DG21E | SHARP | 8.4 | 640×480 |
| LQ104V1DG72 | SHARP | 10.4 | 640×480 |
| SP14Q001 | KOE | 5.7 | 320×240 |
| TX17D200VM0BAA | KOE | 6.5 | 800×480 |
| UG-2864ASYIG01 | WiseChip | 2.7 | 128×64 |
