| Varenummer | LQ057AC111 |
| Mærke | Other |
| Størrelse | 5.7 |
| Ansøgning | IA |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Parallel/Serial |
| panel mærke | CHILIN |
| panel model | LQ057AC111 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.7 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 115.2×86.4 mm |
| omrids | 126×101.55 mm |
| overflade | Antiglare |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 200:1 (Typ.) |
| vise farver | 16.7M |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S7PWLEDWithout Driver |
| signal interface | Digital RGB (8/24-bit), CCIR601/656, 50 pins |
| indgangsspænding | 3.3/5.0V (Typ.)(VDD/AVDD) |
| Ansøgning | IA |
