| Varenummer | AM-800480LATMQW-TN0H |
| Mærke | AMPIRE |
| Størrelse | 5.0 |
| Ansøgning | IA |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 360 |
| CR | 250:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AMPIRE |
| panel model | AM-800480LATMQW-TN0H |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 108×64.8 mm |
| omrids | 118.5×74×5.16 mm |
| overflade | |
| lysstyrke | 360 cd/m² (Typ.) |
| kontrastforhold | 250:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193152% |
| responstid | 15/35 (Max.)(Tr/Td) |
| synsvinkel | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S6PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 45 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
