| Varenummer | AM-800480LTMQW-W0H |
| Mærke | AMPIRE |
| Størrelse | 5.0 |
| Ansøgning | IA |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 470 |
| CR | 250:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | AMPIRE |
| panel model | AM-800480LTMQW-W0H |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 108×64.8 mm |
| omrids | 118.5×77.1×6.37 mm |
| overflade | |
| lysstyrke | 470 cd/m² (Typ.) |
| kontrastforhold | 250:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/70/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S6PWLEDEmbedded (LED Driver) |
| signal interface | CPU, 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
