| Varenummer | AMS410GC01-0 |
| Mærke | Samsung |
| Størrelse | 4.1 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | OLED |
| Lysstyrke | 200 |
| CR | 2000:1 |
| Farver | 262K |
| Baggrundsbelysning | self |
| Interface | TTL |
| panel mærke | SAMSUNG SMD |
| panel model | AMS410GC01-0 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 4.1 inch |
| løsning | 480RG(BG)×800 , WVGA |
| aktivt område | 53.28×88.8 mm |
| omrids | 56.94×97.2 mm |
| overflade | Hard coating |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 2000 : 1 (Min.) |
| vise farver | 262K (6-bit), CIE1931106% |
| synsvinkel | |
| frekvens | 60Hz |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 55 pins |
| indgangsspænding | 2.8/2.8/3.8V (Typ.)(IOVCC/VCI/VBAT) |
| Ansøgning | MPH |
