| Varenummer | BV055FHM-N00 |
| Mærke | BOE |
| Størrelse | 5.5 |
| Ansøgning | MPH |
| Løsning | 1080×1920 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | BOE |
| panel model | BV055FHM-N00 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 5.5 inch |
| løsning | 1080(RGB)×1920 , FHD |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 68.04×120.96 mm |
| omrids | 70.44×127.61 mm |
| overflade | |
| transmissivitet | 4.2% (Typ.)(with Polarizer) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | Suggest NT35532, HX8398-B |
| Ansøgning | MPH |
