| Varenummer | LS030B3UX01D |
| Mærke | SHARP |
| Størrelse | 3.0 |
| Ansøgning | MPH |
| Løsning | 240×400 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | SHARP |
| panel model | LS030B3UX01D |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 3.0 inch |
| løsning | 240(RGB)×400 , WQVGA |
| visningstilstand | Normally Black |
| aktivt område | 38.88×64.8 mm |
| omrids | 45.08×75 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 500 : 1 (Typ.) |
| vise farver | 262K , CIE193175% |
| responstid | 11/24 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1S5PWLEDWithout Driver |
| signal interface | CPU, 40 pins |
| indgangsspænding | 1.8/2.8V (Typ.)(VDDIO/VCC) |
| Ansøgning | MPH |
