| Varenummer | LS063K3SX01 |
| Mærke | SHARP |
| Størrelse | 6.3 |
| Ansøgning | MPH |
| Løsning | 720×1280 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | SHARP |
| panel model | LS063K3SX01 |
| paneltype | CG-Silicon , LCM |
| panelstørrelse | 6.3 inch |
| løsning | 720(RGB)×1280 , WXGA |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 78.3×139.2 mm |
| omrids | 81.7×146.95×1.62 mm |
| overflade | Clear |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193174% |
| responstid | |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥5)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S2PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 40 pins |
| indgangsspænding | 1.8/5.0/-5.0V (Typ.)(IOVDD/AVDD+/AVDD-) |
| Ansøgning | MPH |
