| Varenummer | AV123Z7T-A19-D8P0 |
| Mærke | BOE |
| Størrelse | 12.3 |
| Ansøgning | Outdoor High Brightn |
| Løsning | 1920×720 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 1100:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 9S4P |
| Interface | LVDS |
| fabrikant | BOE |
| modelnavn | AV123Z7T-A19-D8P0 |
| skærmstørrelse | 12.3 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 1920(RGB)×720 167PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 292.032 × 109.512 (H×V) |
| omrids (mm) | 345.19 × 149.1 × 27.93 (H×V×D) |
| rammeareal (mm) | - |
| behandling | Anti Fingerprint + Antiglare, Hard coating (3H) |
| luminans | 850 cd/m² (Typ.) |
| kontrastforhold | 1100 : 1 (Typ.) (TM) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| respons | 25 (Max.)(Tr+Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | IPS, Normally Black, Transmissive |
| farvedybde | 16.7M 80% NTSC |
| baggrundsbelysning | 9S4P WLED , 50K hours , No Driver |
| masse | - |
| anvendes til | Outdoor High Brightness Automotive Display |
| opdateringshastighed | 60Hz |
| berøringsskærm | PCAP |
| signaltype | LVDS (2 ch, 8-bit) , Connector 60 pins |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C |
