| Varenummer | C123HAN01.0 |
| Mærke | AUO |
| Størrelse | 12.3 |
| Ansøgning | CNS |
| Løsning | 1920×720 |
| Sammensætning | LCM |
| Lysstyrke | 700 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | C123HAN01.0 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.3 inch |
| løsning | 1920(RGB)×720 |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 292.32×109.62 mm |
| omrids | 308.1×134.86×15.6 mm |
| overflade | Antiglare |
| lysstyrke | 700 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 12/13 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S2PWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | CNS |
