| Varenummer | TX31D200VM0BAA |
| Mærke | KOE |
| Størrelse | 12.3 |
| Ansøgning | IA |
| Løsning | 1280×480 |
| Sammensætning | LCM |
| Lysstyrke | 1000 |
| CR | 1000:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | KOE |
| panel model | TX31D200VM0BAA |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.3 inch |
| løsning | 1280(RGB)×480 , DVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 291.84×109.44 mm |
| omrids | 320×130×12.6 mm |
| overflade | Antiglare |
| lysstyrke | 1000 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193170% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
