| Varenummer | LP097QX2-SPAV |
| Mærke | LG Display |
| Størrelse | 9.7 |
| Ansøgning | PAD |
| Løsning | 1536×2048 |
| Sammensætning | LCM |
| Lysstyrke | 440 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | LG Display |
| panel model | LP097QX2-SPAV |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 9.7 inch |
| løsning | 1536(RGB)×2048 , QXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 147.456×196.608 mm |
| omrids | 160.3×208.93 mm |
| overflade | Glare (Haze 0%), Hard coating (3H), Antireflection |
| lysstyrke | 440 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | eDP (4 Lanes), 42 pins |
| indgangsspænding | 3.7V (Typ.) |
| Ansøgning | PAD |
