| Varenummer | LTN097XL02-A01 |
| Mærke | Samsung |
| Størrelse | 9.7 |
| Ansøgning | PAD |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 440 |
| CR | 900:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN097XL02-A01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 9.7 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | PLS, Normally Black, Transmissive |
| aktivt område | 196.608×147.456 mm |
| omrids | 210.33×164.37×5.12 mm |
| overflade | Hard coating (2H) |
| lysstyrke | 440 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6 stringsWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| BF097XN | Innolux | 9.7 | 1024×768 |
| BI097XN02 V.Y | Innolux | 9.7 | 1024×768 |
| LP097QX1-SPC1 | LG Display | 9.7 | 2048×1536 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097X02-SLN1 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLQE | LG Display | 9.7 | 1024×768 |
| LTN097XL01-A01 | Samsung | 9.7 | 1024×768 |
| LTN097XL01-A02 | Samsung | 9.7 | 1024×768 |
| LTN097XL02-A01 | Samsung | 9.7 | 1024×768 |
| TM097TDH01 | Tianma | 9.7 | 1024×768 |
| B101EAN01.7 | AUO | 10.1 | 1280×800 |
| HSD100PXN1-A00-C40 | HannStar | 10.0 | 1024×768 |
| HV070WS1-105 | HYDIS | 7.0 | 1024×600 |
| HV121WX4-110 | HYDIS | 12.1 | 1280×800 |
| HV121WX5-113 | HYDIS | 12.1 | 1280×800 |
| HV121WX5-121 | HYDIS | 12.1 | 1280×800 |
| LC104S1-A1 | LG Display | 10.4 | 800×600 |
| LD089WX1-SL03 | LG Display | 8.9 | 1280×768 |
| LTN070NL01 | Samsung | 7.0 | 1024×600 |
| N101ICG-L11 | Innolux | 10.1 | 1280×800 |
