| Varenummer | VVX07F023B00 |
| Mærke | Panasonic |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 1200×1920 |
| Sammensætning | LCM |
| Lysstyrke | 430 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | Panasonic |
| panel model | VVX07F023B00 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 1200(RGB)×1920 , WUXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 94.5×151.2 mm |
| omrids | 104×161.37×3.9 mm |
| overflade | Antireflection |
| lysstyrke | 430 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193160% |
| responstid | 30 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥100)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4S6PWLEDEmbedded (LED Driver) |
| signal interface | MIPI (4 data lanes), 31 pins |
| indgangsspænding | 3.4V (Typ.) |
| Ansøgning | PAD |
