| Varenummer | BP070WX1-300 |
| Mærke | BOE |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 800×1280 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | BOE |
| panel model | BP070WX1-300 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×1280 , WXGA |
| visningstilstand | AFFS, Normally Black, Transmissive |
| aktivt område | 94.2×150.72 mm |
| omrids | 99.7×160.93×3.8 mm |
| overflade | Hard coating (3H), Antireflection |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193150% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5S4PWLEDWithout Driver |
| signal interface | MIPI, 34 pins |
| indgangsspænding | 1.8/3.3V (Typ.)(IOVCC/VDD) |
| Ansøgning | PAD |
