| Varenummer | BRS315H2 |
| Mærke | |
| Størrelse | 31.5 |
| Ansøgning | PID |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 2000 |
| CR | 5000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | BERISE |
| panel model | BRS315H2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 31.5 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 698.4×392.85 mm |
| omrids | 730.94×429.84 mm |
| overflade | Antiglare (Haze 2%), Hard coating (3H) |
| lysstyrke | 2000 cd/m² (Typ.) |
| kontrastforhold | 5000:1 (Typ.) |
| vise farver | 1.07B (10-bit), CIE193180% |
| responstid | 8 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| BRS315H2 | 31.5 | 1920×1080 | |
| LC320EUD-SDA2 | LG Display | 31.5 | 1920×1080 |
| LC320EUN-FFM1 | LG Display | 31.5 | 1920×1080 |
| LQ315D1JG03 | SHARP | 31.5 | 3840×2160 |
| LTA320HJ03 | Samsung | 31.5 | 1920×1080 |
| LTF320HM01 | Samsung | 31.5 | 1920×1080 |
| ST3151A04-8 | CSOT | 31.5 | 1366×768 |
| T315HW01 V0 | AUO | 31.5 | 1920×1080 |
| T315HW05 V5 | AUO | 31.5 | 1920×1080 |
| V315B5-L01 | Innolux | 31.5 | 1366×768 |
| LD470EUD-SDA1 | LG Display | 47 | 1920×1080 |
| LD840EQD-SEM1 | LG Display | 84 | 3840×2160 |
| LTI400HA01 | Samsung | 40 | 1920×1080 |
| LTI460AP01-101 | Samsung | 46 | 1366×768 |
| LTI460HM02 | Samsung | 46 | 1920×1080 |
| LTI750HF01 | Samsung | 75 | 1920×1080 |
| ND168TXP01 | 16.8 | 1366×378 | |
| P320HVN01.0 | AUO | 31.5 | 1920×1080 |
| P420HW02 V0 | AUO | 42 | 1920×1080 |
| P645HW01 V0 | AUO | 65 | 1920×1080 |
