| Varenummer | CLAF040LE21 AX |
| Mærke | CPT |
| Størrelse | 4.0 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 700:1 |
| Farver | |
| Baggrundsbelysning | No B/L |
| Interface | |
| panel mærke | CPT |
| panel model | CLAF040LE21 AX 1 Compatible model |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 4.0 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 51.84×86.4 mm |
| omrids | 55.44×93.9×0.6 mm |
| overflade | Without Polarizer |
| glas dybde | 0.30+0.30 mm |
| transmissivitet | 4.1% (Typ.)(with Polarizer) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | , CIE193161% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/50/20 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | Suggest NT35510 |
| Ansøgning | MPH |
