| Varenummer | AMFN888 |
| Mærke | Samsung |
| Størrelse | 3.1 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | OLED |
| Lysstyrke | 300 |
| CR | 5000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | self |
| Interface | TTL |
| panel mærke | SAMSUNG SDI |
| panel model | AMFN888 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 3.1 inch |
| løsning | 480RG(BG)×800 , WVGA |
| aktivt område | 40.31×67.2 mm |
| omrids | 45.88×77.2 mm |
| overflade | Hard coating (2H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 5000 : 1 (Min.) |
| vise farver | 16.7M (8-bit), CIE1931106% |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| driver ic | Built-in TL2796 |
| signal interface | Parallel RGB (1 ch, 8-bit), 45 pins |
| indgangsspænding | 1.8/2.8/3.8V (Typ.)(VDD3/VCI/VBAT) |
| Ansøgning | MPH |
| AMFN888 | Samsung | 3.1 | 480×800 |
| AMS427GL45-0 | Samsung | 4.3 | 480×800 |
| BT055FWM-N00 | BOE | 5.5 | 480×854 |
| BTL455496-W613L | BOE | 4.5 | 540×960 |
| BV055FHM-N00 | BOE | 5.5 | 1080×1920 |
| H345VW01 V0 | AUO | 3.5 | 480×800 |
| H466TAN01.0 | AUO | 4.7 | 720×1280 |
| LMS340KC01-001 | Samsung | 3.4 | 720×480 |
| LS041Y3LW01 | SHARP | 4.1 | 800×480 |
| TM028HBHG02 | Tianma | 2.8 | 240×320 |
