| Varenummer | LH350WS1-SD01 |
| Mærke | LG Display |
| Størrelse | 3.5 |
| Ansøgning | MPH |
| Løsning | 640×960 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | LG Display |
| panel model | LH350WS1-SD01 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 640(RGB)×960 , DVGA |
| visningstilstand | IPS, Normally Black, Transflective |
| aktivt område | 49.92×74.88 mm |
| omrids | 54.85×82.93×1.52 mm |
| overflade | |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.)(Transmissive) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 20/20 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | MIPI, 26 pins |
| indgangsspænding | 5.672/1.8V (Typ.)(AVDDH/DVDD) |
| Ansøgning | MPH |
