| Varenummer | 43WVF3A |
| Mærke | SII |
| Størrelse | 4.3 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SII |
| panel model | 43WVF3A |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | FFS, Normally Black, Transmissive |
| aktivt område | 56.16×93.6 mm |
| omrids | 61.66×108.2 mm |
| overflade | Antiglare |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.2M (6-bit + Dithering), CIE193172% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 8S1PWLED |
| signal interface | Parallel RGB (1 ch, 6/8-bit) + SPI, 61 pins |
| Ansøgning | MPH |
| CLAN053WA31 2AX | CPT | 5.3 | 720×1280 |
| DLC0240LZG-4 | Other | 2.4 | 240×320 |
| H335VL01 V0 | AUO | 3.4 | 480×854 |
| LH430WV1-SD02 | LG Display | 4.3 | 480×800 |
| LMS283GF11 | Samsung | 2.8 | 240×320 |
| LMS316CC01 | Samsung | 3.2 | 640×360 |
| LQ043T1LX01A | SHARP | 4.3 | 540×960 |
| LQ055K3SX02 | SHARP | 5.5 | 720×1280 |
| LS040B3SX01 | SHARP | 4.0 | 640×960 |
| TM020GDH42 | Tianma | 2.0 | 176×220 |
