| Varenummer | CLAA050JA01CT |
| Mærke | CPT |
| Størrelse | 5.0 |
| Ansøgning | CNS |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 320 |
| CR | 350:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | CPT |
| panel model | CLAA050JA01CT |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 110.88×62.832 mm |
| omrids | 120.7×75.8×4.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 320 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 10S1PWLEDWithout Driver |
| signal interface | TTL (1 ch, 8-bit), 50 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | CNS |
