| Varenummer | CLAA101WJ02 |
| Mærke | CPT |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CPT |
| panel model | CLAA101WJ02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.1 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | HFFS, Normally Black, Transmissive |
| aktivt område | 223.341×125.568 mm |
| omrids | 234.53×138.97×4.4 mm |
| overflade | Hard coating |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Min.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S6PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| CLAA101NC05 | CPT | 10.1 | 1024×600 |
| CLAA101ND02CW | CPT | 10.1 | 1024×600 |
| CLAA102NC01CW | CPT | 10.2 | 1024×600 |
| CLAA104XA12BW | CPT | 10.4 | 1024×768 |
| CLAA121UA01CW | CPT | 12.1 | 1600×900 |
| CLAA141WB11 | CPT | 14.1 | 1280×800 |
| CLAA150XP01 | CPT | 15.0 | 1024×768 |
| CLAA154WA01 | CPT | 15.4 | 1280×800 |
| CLAA156WB11A | CPT | 15.6 | 1366×768 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| HSD101PWW1-A00 | HannStar | 10.1 | 1280×800 |
| LP097X02-SLA2 | LG Display | 9.7 | 1024×768 |
| LP101WH4-SLA3 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLAA | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLP2 | LG Display | 10.1 | 1366×768 |
| LP125WH2-SLT2 | LG Display | 12.5 | 1366×768 |
| LTN121AP05-302 | Samsung | 12.1 | 1280×800 |
| N070ICE-G02 Rev.A2 | Innolux | 7.0 | 800×1280 |
| TV080X0M-NS0 | BOE | 8.0 | 768×1024 |
