| Varenummer | DLC0700MIG |
| Mærke | Other |
| Størrelse | 7.0 |
| Ansøgning | MP4 |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | DLC |
| panel model | DLC0700MIG |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 152.4×91.44 mm |
| omrids | 165×104 mm |
| overflade | |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | TTL (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.)(VCC) |
| Ansøgning | MP4 |
| DLC0700BZG-7 | Other | 7.0 | 800×480 |
| DLC0700CZG-6 | Other | 7.0 | 800×480 |
| DLC0700DDG-4 | Other | 7.0 | 800×480 |
| DLC0700EZG-1 | Other | 7.0 | 800×480 |
| DLC0700FDG-T-6 | Other | 7.0 | 800×480 |
| DLC0700JBG-T-6 | Other | 7.0 | 1024×600 |
| DLC0700OZG-T-1 | Other | 7.0 | 800×480 |
| DLC0700WZG | Other | 7.0 | 1200×1920 |
| DLC0700YZG-1 | Other | 7.0 | 1024×600 |
| DLC0700YZG-T-6 | Other | 7.0 | 1024×600 |
| AT070TN82 | Innolux | 7.0 | 800×480 |
| BA070WS1-402 | BOE | 7.0 | 1024×600 |
| CLAA070ND26CW | CPT | 7.0 | 1024×600 |
| DLC0700JMG-6 | Other | 7.0 | 1024×600 |
| HSD070PFW3-B02 | HannStar | 7.0 | 1024×600 |
| LB070WV4-TJ01 | LG Display | 7.0 | 800×480 |
| LMS700KF05 | Samsung | 7.0 | 800×480 |
| LW700AT9009 | Innolux | 7.0 | 800×480 |
| TM050RBH01 | Tianma | 5.0 | 800×480 |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
