| Varenummer | DLC0700WZG |
| Mærke | Other |
| Størrelse | 7.0 |
| Ansøgning | HHP |
| Løsning | 1200×1920 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 1200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | DLC |
| panel model | DLC0700WZG |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 1200(RGB)×1920 , WUXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 94.5×151.2 mm |
| omrids | 98.7×160.8 mm |
| overflade | |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 30/10 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4S4PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 40 pins |
| indgangsspænding | 1.8/5.5/-5.5V (Typ.)(IOVCC/VSP/VSN) |
| Ansøgning | HHP |
