| Varenummer | ET035009DH6 |
| Mærke | EDT |
| Størrelse | 3.5 |
| Ansøgning | IA |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | EDT |
| panel model | ET035009DH6 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 70.08×52.56 mm |
| omrids | 76.8×63.8 mm |
| overflade | |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 75/75/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| indgangsspænding | 3.3/3.3V (Typ.)(VCC/VDD) |
| Ansøgning | IA |
| ACX502BMU-7 | SONY | 3.5 | 240×320 |
| COM35H3P09UTC | ORTUSTECH | 3.5 | 480×640 |
| EL160.80.50 ET | Lumineq | 3.5 | 160×80 |
| ET035009DH6 | EDT | 3.5 | 320×240 |
| LH350H01-FD01 | LG Display | 3.5 | 320×480 |
| LTV035QV-F09 | Samsung | 3.5 | 320×240 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| NL2432HC22-32B | NLT | 3.5 | 240×320 |
| NL4864HL11-01B | NLT | 3.5 | 480×640 |
| PD035QX2 | E Ink | 3.5 | 320×240 |
| AA065VE11ADA11 | Mitsubishi | 6.5 | 640×480 |
| AA104VC06 | Mitsubishi | 10.4 | 640×480 |
| AT104XH11 | Mitsubishi | 10.4 | 1024×768 |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| G156HAN01.0 | AUO | 15.6 | 1920×1080 |
| LQ9D023 | SHARP | 8.4 | 640×480 |
| M121MNS1 R0 | IVO | 12.1 | 800×600 |
| MD400T640PD1 | Panasonic | 9.4 | 640×400 |
| PD064VT8 | E Ink | 6.4 | 640×480 |
| TS104SAALC01-00 | Tianma | 10.4 | 800×600 |
