| Varenummer | COM35H3P09UTC |
| Mærke | ORTUSTECH |
| Størrelse | 3.5 |
| Ansøgning | HHP |
| Løsning | 480×640 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | ORTUSTECH |
| panel model | COM35H3P09UTC 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 480(RGB)×640 , VGA |
| visningstilstand | Buenaview, Normally Black, Transflective |
| aktivt område | 53.28×71.04 mm |
| omrids | 63.5×85×5.83 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.)(Transmissive)5.5:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit) |
| responstid | 40/60 (Max.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 39 pins |
| indgangsspænding | 3.0/1.8V (Typ.)(VDD/VCCIO) |
| Ansøgning | HHP |
| 35WVF1H | SII | 3.5 | 480×800 |
| AMS347FF02 | Samsung | 3.5 | 360×640 |
| COM35H3M10XTC | ORTUSTECH | 3.5 | 240×320 |
| COM35H3M74UTC | ORTUSTECH | 3.5 | 480×640 |
| COM35H3P09UTC | ORTUSTECH | 3.5 | 480×640 |
| H347QVN02.0 | AUO | 3.5 | 320×480 |
| LQ035Q1DH02 | SHARP | 3.5 | 320×240 |
| LQ035Q5DG01 | SHARP | 3.5 | 320×240 |
| PD035QX1 | E Ink | 3.5 | 240×320 |
| PT035TN23 V.3 | Innolux | 3.5 | 320×240 |
| COM32H3N74ULC | ORTUSTECH | 3.2 | 480×800 |
| DLC0090AZG | Other | 0.91 | 80×160 |
| G043FTT01.0 | AUO | 4.3 | 480×272 |
| LM038QC1R10 | SHARP | 3.8 | 320×240 |
| LQ038B7DB01 | SHARP | 3.8 | 320×480 |
| LQ043T1DG28 | SHARP | 4.3 | 480×272 |
| LS024Q3UX12(G) | SHARP | 2.4 | 320×240 |
| LS037V7DW03 | SHARP | 3.7 | 480×640 |
| TM030LDHT2 | Tianma | 3.0 | 240×400 |
| TX09D30VM1CCA | KOE | 3.5 | 240×320 |
