| Varenummer | LQ6AN101 |
| Mærke | SHARP |
| Størrelse | 5.6 |
| Ansøgning | VDP |
| Løsning | 320×234 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 100:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | SHARP |
| panel model | LQ6AN101 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.6 inch |
| løsning | 320(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 114.2×83.5 mm |
| omrids | 140×102.7×20 mm |
| overflade | |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 100:1 (Min.) |
| vise farver | Full color |
| responstid | 15/20 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLEmbedded (Inverter) |
| signal interface | Analog RGB + Composite Video (NTSC/PAL), 24 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | VDP |
| A056DN01 V2 | AUO | 5.6 | 320×234 |
| AT056TN03 | Innolux | 5.6 | 320×234 |
| AT056TN53 V.1 | Innolux | 5.6 | 640×480 |
| C-51849NFJ-SLW-ADN | Kyocera | 5.6 | 40×4 |
| FX050605DNCWAG03 | Data Image | 5.6 | |
| HV056WX1-101 | HYDIS | 5.6 | 1280×800 |
| LQ056A3AG01 | SHARP | 5.6 | 320×234 |
| LQ6AN101 | SHARP | 5.6 | 320×234 |
| LTD056EV7F00 | TOSHIBA | 5.6 | 1280×800 |
| TM056KDH01 | Tianma | 5.6 | 320×234 |
| A040CN01 V2 | AUO | 4.0 | 480×234 |
| CLAA070WA03 | CPT | 7.0 | 480×234 |
| HSD050I551-A00 | HannStar | 5.0 | 320×234 |
| HSD070I651-F20 | HannStar | 7.0 | 480×234 |
| LB065W01-B11B | LG Display | 6.5 | 400×234 |
| LB070W02-TMJ2 | LG Display | 7.0 | 480×234 |
| LQ050A3AD01 | SHARP | 5.0 | 320×234 |
| LQ070T3AG02 | SHARP | 7.0 | 480×234 |
| LTA065B096D | TOSHIBA | 6.5 | 400×234 |
| TM056KDH01 | Tianma | 5.6 | 320×234 |
