| Varenummer | LTD056ET0S |
| Mærke | TOSHIBA |
| Størrelse | 5.6 |
| Ansøgning | UMPC |
| Løsning | 1024×600 |
| Sammensætning | LCM |
| Lysstyrke | 165 |
| CR | 200:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | Toshiba Matsushita |
| panel model | LTD056ET0S |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 5.6 inch |
| løsning | 1024(RGB)×600 , WSVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 122.88×72 mm |
| omrids | 141.8×84.4 mm |
| overflade | |
| lysstyrke | 165 cd/m² (Typ.) |
| kontrastforhold | 200:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 50 (Max.)(Tr+Td) |
| synsvinkel | 40/40/25/30 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 25 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | UMPC |
