| Varenummer | LA070WV6-SD01 |
| Mærke | LG Display |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 610 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | LG Display |
| panel model | LA070WV6-SD01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 152.4×91.44 mm |
| omrids | 166.6×105.8×10.5 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 610 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193160% |
| responstid | 15/10 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 66 pins |
| indgangsspænding | 3.3/13.0/18.5/-7.5V (Typ.)(DVDD/AVDD/VGH/VGL) |
| Ansøgning | CNS |
| LA070WV1-TD01 | LG Display | 7.0 | 800×480 |
| LA070WV1-TD03 | LG Display | 7.0 | 800×480 |
| LA070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LA070WV1-TH01 | LG Display | 7.0 | 800×480 |
| LA070WV4-SD01 | LG Display | 7.0 | 800×480 |
| LA070WV4-SD03 | LG Display | 7.0 | 800×480 |
| LA070WV4-SD04 | LG Display | 7.0 | 800×480 |
| LA070WV5-SL01 | LG Display | 7.0 | 800×480 |
| LA070WV6-SD01 | LG Display | 7.0 | 800×480 |
| LA070WV6-SL01 | LG Display | 7.0 | 800×480 |
| C050FTN01.0 | AUO | 5.0 | 480×234 |
| C065GW02 V1 | AUO | 6.5 | 400×234 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| DLC0700BZG-7 | Other | 7.0 | 800×480 |
| G104V1-T01 | Innolux | 10.4 | 640×480 |
| G150X1-L01 | Innolux | 15.0 | 1024×768 |
| HSD070PFW3-C01 | HannStar | 7.0 | 1024×600 |
| LA070WV6-SL02 | LG Display | 7.0 | 800×480 |
| LB035Q03-TD02 | LG Display | 3.5 | 320×240 |
| TFD58W22MW | TOSHIBA | 5.8 | 400×234 |
