| Varenummer | LB070WQ5-TD01 |
| Mærke | LG Display |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 480×240 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | LG.Philips LCD |
| panel model | LB070WQ5-TD01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 480(RGB)×240 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 155.952×82.8 mm |
| omrids | 168.8×93.5 mm |
| overflade | Antiglare |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 10/20 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | CCFL |
| signal interface | TTL (1 ch, 6-bit), 40 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | CNS |
