| Varenummer | LB080WV4-TA01 |
| Mærke | LG Display |
| Størrelse | 8.0 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | LG.Philips LCD |
| panel model | LB080WV4-TA01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 176.64×99.36 mm |
| omrids | 216.5×121 mm |
| overflade | Antiglare |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 10/20 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/60/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLEmbedded (Inverter) |
| signal interface | Analog RGB + Composite Video (NTSC/PAL), 20 pins |
| indgangsspænding | 13.8V (Typ.)(VCC) |
| Ansøgning | CNS |
| A080SN03 V0 | AUO | 8.0 | 800×600 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| EJ080NA-05A | Innolux | 8.0 | 800×600 |
| LB080WV3-A3 | LG Display | 8.0 | 800×480 |
| LB080WV3-B1 | LG Display | 8.0 | 800×480 |
| LB080WV4-A1 | LG Display | 8.0 | 800×480 |
| LB080WV4-TA01 | LG Display | 8.0 | 800×480 |
| LB080WV4-TD02 | LG Display | 8.0 | 800×480 |
| LB080WV6-TA03 | LG Display | 8.0 | 800×480 |
| LQ080T5GG01B | SHARP | 8.0 | 480×234 |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C070FW02 V0 | AUO | 7.0 | 480×234 |
| CLAA070LF06CW | CPT | 7.0 | 800×480 |
| LA070WV4-SD04 | LG Display | 7.0 | 800×480 |
| LA070WV6-SL01 | LG Display | 7.0 | 800×480 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LQ058T5BA01 | SHARP | 5.8 | |
| LQ058T5DR02 | SHARP | 5.8 | 480×272 |
| LQ080Y5DZ30A | SHARP | 8.0 | 800×480 |
| ZJ080NA-08A | Innolux | 8.0 | 1024×600 |
