| Varenummer | LB070WV3-SD01 |
| Mærke | LG Display |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 470 |
| CR | 900:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | LG Display |
| panel model | LB070WV3-SD01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 152.4×91.44 mm |
| omrids | 170×109.6×29.4 mm |
| overflade | Antiglare, Antireflection |
| lysstyrke | 470 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 15/14 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/30/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S3PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | CNS |
| LB070W02-TMJ2 | LG Display | 7.0 | 480×234 |
| LB070WQ5-TD01 | LG Display | 7.0 | 480×240 |
| LB070WV1-TD07 | LG Display | 7.0 | 800×480 |
| LB070WV1-TD17 | LG Display | 7.0 | 800×480 |
| LB070WV3-SD02 | LG Display | 7.0 | 800×480 |
| LB070WV3-SD03 | LG Display | 7.0 | 800×480 |
| LB070WV4-SD01 | LG Display | 7.0 | 800×480 |
| LB070WV6-TD06 | LG Display | 7.0 | 800×480 |
| LB070WV7-TD01 | LG Display | 7.0 | 800×480 |
| LB070WV8-SL01 | LG Display | 7.0 | 800×480 |
| CLAA070NJ07CW | CPT | 7.0 | 1024×600 |
| L5S30883P00 | SANYO | 4.5 | 480×240 |
| LB070WV7-TD02 | LG Display | 7.0 | 800×480 |
| LB080WV4-TD02 | LG Display | 8.0 | 800×480 |
| LQ049B5DG04 | SHARP | 4.9 | 320×96 |
| LQ065T5GG63 | SHARP | 6.5 | 400×234 |
| LTA070B052F | TOSHIBA | 7.0 | 800×480 |
| PA080XS4 | E Ink | 7.9 | 480×468 |
| PM065WX3 | E Ink | 6.5 | 800×480 |
| TM060RDH01 | Tianma | 6.0 | 800×480 |
