| Varenummer | LD050WQ1-TD02 |
| Mærke | LG Display |
| Størrelse | 5.0 |
| Ansøgning | DPF |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | |
| panel mærke | LG Display |
| panel model | LD050WQ1-TD02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 480×272(RGB) , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 110.88×62.832 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (6-bit + Dithering), CIE193148% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/65/55 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | WLED |
| Ansøgning | DPF |
| A050VW02 V0 | AUO | 5.0 | 480×800 |
| AM-800480LATMQW-TN0H | AMPIRE | 5.0 | 800×480 |
| LD050WQ1-TD02 | LG Display | 5.0 | 480×272 |
| LD050WV1-SP01 | LG Display | 5.0 | 480×800 |
| LQ050W1LA0A | SHARP | 5.0 | 1024×600 |
| LTE052T-4301-1 | TPO | 5.0 | 320×234 |
| P50CD4 | E Ink | 5.0 | 320×234 |
| PJ050IA-14A | Innolux | 5.0 | 720×1280 |
| PW050XS3 | E Ink | 5.0 | 320×220 |
| YXDK050TN02-40NM03 | SEBO | 5.0 | 800×480 |
| A080SN03 V2 | AUO | 8.0 | 800×600 |
| A101VW01 V1 | AUO | 10.1 | 800×480 |
| AT070TN84 | Innolux | 7.0 | 800×480 |
| AT080TN52 | Innolux | 8.0 | 800×600 |
| CLAA101ND02CW | CPT | 10.1 | 1024×600 |
| HSD100IFW1-A00 | HannStar | 10.1 | 1024×600 |
| HSD100IFW1-F03 | HannStar | 10.1 | 1024×600 |
| LTE700WQ-F05 | Samsung | 7.0 | 480×234 |
| LTP700WV-F02 | Samsung | 7.0 | 800×480 |
| TX31D50VM2BAA | KOE | 12.0 | 800×480 |
