| Varenummer | LTE700WQ-F05 |
| Mærke | Samsung |
| Størrelse | 7.0 |
| Ansøgning | DPF |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | SAMSUNG |
| panel model | LTE700WQ-F05 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 480×234(RGB) |
| visningstilstand | TN, Normally White, TMR |
| aktivt område | 154.08×86.58 mm |
| omrids | 166×100×7.2 mm |
| overflade | |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 500 : 1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 13/17 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/55/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| indgangsspænding | 2.5/3.3V (Typ.)(VDD) |
| Ansøgning | DPF |
| CLAA070LC0DCW | CPT | 7.0 | 800×480 |
| CLAA070NJ07CW | CPT | 7.0 | 1024×600 |
| CLAA070VA01 | CPT | 7.0 | 800×480 |
| CLAA070WP03XG | CPT | 7.0 | 800×1280 |
| G070Y2-T02 | Innolux | 7.0 | 800×480 |
| HSD070IDW1-E11 | HannStar | 7.0 | 800×480 |
| LQ070T5GC01 | SHARP | 7.0 | |
| LTA070B511F | TOSHIBA | 7.0 | 800×480 |
| LTE700WQ-F05 | Samsung | 7.0 | 480×234 |
| M070SW46 R0 | IVO | 7.0 | 1200×1920 |
| A070SN02 V0 CELL | AUO | 7.0 | 800×600 |
| AT080TN43 | Innolux | 8.0 | 800×600 |
| AT080TN52 V.1 | Innolux | 8.0 | 800×600 |
| AT090TN10 | Innolux | 9.0 | 800×480 |
| AT102TN03 V.1 | Innolux | 10.2 | 800×480 |
| EJ080NA-05A | Innolux | 8.0 | 800×600 |
| HSD100IFW1-A00 | HannStar | 10.1 | 1024×600 |
| LQ080T3AG01 | SHARP | 8.0 | 480×234 |
| PA079DS1T2 | E Ink | 7.9 | 480×234 |
| Q07021-701 | Innolux | 7.0 | 800×600 |
