| Varenummer | LD050WV1-SP01 |
| Mærke | LG Display |
| Størrelse | 5.0 |
| Ansøgning | UMPC |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 700:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | LG Display |
| panel model | LD050WV1-SP01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 64.8×108 mm |
| omrids | 71.4×120.4×4.31 mm |
| overflade | Antiglare |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 5S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 40 pins |
| indgangsspænding | 2.9V (Typ.) |
| Ansøgning | UMPC |
