| Varenummer | LMS500HF13-003 |
| Mærke | Samsung |
| Størrelse | 5.0 |
| Ansøgning | PND |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SAMSUNG SMD |
| panel model | LMS500HF13-003 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 480×272(RGB) , WQVGA |
| visningstilstand | VA, Normally Black, TMR |
| aktivt område | 110.88×62.832 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 800 : 1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 17/15 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLED |
| signal interface | Parallel RGB (1 ch, 8-bit) |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PND |
| A050BTS30R0 | Aptus | 5.0 | 480×480 |
| LMS500HF01 | Samsung | 5.0 | 480×272 |
| LMS500HF04-002 | Samsung | 5.0 | 480×272 |
| LMS500HF05 | Samsung | 5.0 | 480×272 |
| LMS500HF06 | Samsung | 5.0 | 480×272 |
| LMS500HF07 | Samsung | 5.0 | 480×272 |
| LMS500HF13-002 | Samsung | 5.0 | 480×272 |
| LMS500HF13-003 | Samsung | 5.0 | 480×272 |
| LS050T1SX12(K) | SHARP | 5.0 | 1080×1920 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
| 43WQW3H | SII | 4.3 | 480×272 |
| A050FW03 V2 | AUO | 5.0 | 480×272 |
| AT043TN13 | Innolux | 4.3 | 480×272 |
| AT043TN25 V.2 | Innolux | 4.3 | 480×272 |
| AT050TN43 V.1 | Innolux | 5.0 | 800×480 |
| DLC0430LZG | Other | 4.3 | 480×272 |
| GPM782A0 | Giantplus | 3.5 | 320×240 |
| LMS500HF04-002 | Samsung | 5.0 | 480×272 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| TM050RDH03 | Tianma | 5.0 | 800×480 |
