| Varenummer | LM7MS623 |
| Mærke | SHARP |
| Størrelse | 6.5 |
| Ansøgning | IA |
| Løsning | 640×240 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | Monochrome |
| Baggrundsbelysning | No B/L |
| Interface | Parallel Data |
| panel mærke | SHARP |
| panel model | LM7MS623 |
| paneltype | FSTN-LCD , LCM |
| panelstørrelse | 6.5 inch |
| løsning | 640×240 , HVGA |
| visningstilstand | STN, Black/White (Positive), Reflective |
| aktivt område | 153.59×57.59 mm |
| omrids | 172.7×76.2 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 10:1 (Typ.)(Reflective) |
| vise farver | Monochrome |
| responstid | 190/220 (Typ.)(Tr/Td) |
| synsvinkel | 20/20/20/25 (Typ.)(CR≥2)(L/R/U/D) |
| frekvens | 70Hz |
| lampe type | No B/L |
| signal interface | Parallel Data (4-bit), 22 pins |
| Ansøgning | IA |
