| Varenummer | LMS480KC02 |
| Mærke | Samsung |
| Størrelse | 4.8 |
| Ansøgning | PND |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SAMSUNG |
| panel model | LMS480KC02 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 4.8 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 104.4×62.64 mm |
| omrids | 112×75 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| indgangsspænding | 3.3/3.3V (Typ.)(VCC/VCCIO) |
| Ansøgning | PND |
