| Varenummer | A040FL01 V2 |
| Mærke | AUO |
| Størrelse | 4.0 |
| Ansøgning | PND |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | A040FL01 V2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.0 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | ATR-MVA, Normally Black, Transflective |
| aktivt område | 87.84×49.776 mm |
| omrids | 98.3×62.6 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.)(Transmissive) |
| vise farver | 16.7M (8-bit) |
| responstid | 20/20 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| indgangsspænding | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| Ansøgning | PND |
| A040FL01 V2 | AUO | 4.0 | 480×272 |
| AMS395GB04 | Samsung | 4.0 | 360×640 |
| COM40T4M46ULX | ORTUSTECH | 4.0 | 480×800 |
| LB040Q02-TD02 | LG Display | 4.0 | 320×240 |
| LB040Q02-TD05 | LG Display | 4.0 | 320×240 |
| LH400WS2-SD03 | LG Display | 4.0 | 640×1136 |
| LH400WV3-SD02 | LG Display | 4.0 | 480×800 |
| LH400WV3-SD05 | LG Display | 4.0 | 480×800 |
| LS040B3SX01 | SHARP | 4.0 | 640×960 |
| LTE400WQ-E01 | Samsung | 4.0 | 480×272 |
| A050FW03 V2 | AUO | 5.0 | 480×272 |
| DLC0500HZG-T-8 | Other | 5.0 | 800×480 |
| HE050NA-01F | Innolux | 5.0 | 800×480 |
| LMS500HF13-003 | Samsung | 5.0 | 480×272 |
| LQ035Q1DG02 | SHARP | 3.5 | 320×240 |
| LQ043T3DG02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX02 | SHARP | 4.3 | 480×272 |
| LQ043T3LX02 | SHARP | 4.3 | 480×272 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
| PT035TN01 V.3 | Innolux | 3.5 | 320×240 |
