| Varenummer | LR043JC111 |
| Mærke | Innolux |
| Størrelse | 4.3 |
| Ansøgning | PND |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | ChiHsin |
| panel model | LR043JC111 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480(RGB)×272 , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 95.04×53.856 mm |
| omrids | 105.5×67.2 mm |
| overflade | Antiglare |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 15/35 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 40 pins |
| indgangsspænding | 3.0/5.0V (Typ.)(VCC/VDD) |
| rohs: | |
| Ansøgning | PND |
| 43WQW4T | SII | 4.3 | 480×272 |
| A043FW02 V0 | AUO | 4.3 | 480×272 |
| AM-480272-043D | Other | 4.3 | 480×272 |
| ED043CA-01D | Innolux | 4.3 | 480×272 |
| LMS430HF11-003 | Samsung | 4.3 | 480×272 |
| LMS430HF20 | Samsung | 4.3 | 480×272 |
| LR043AC212 | Innolux | 4.3 | 480×272 |
| LR043JC111 | Innolux | 4.3 | 480×272 |
| LR043JC211 | Innolux | 4.3 | 480×272 |
| TX11D101VM0EAA | KOE | 4.3 | 480×800 |
| AM480272H3TMQW-T00H | AMPIRE | 4.3 | 480×272 |
| DLC0430LZG-6 | Other | 4.3 | 480×272 |
| ED043CA-01D | Innolux | 4.3 | 480×272 |
| LB035Q04-TD08 | LG Display | 3.5 | 320×240 |
| LB050WQ3-TD04 | LG Display | 5.0 | 480×272 |
| LQ043T1DG01 | SHARP | 4.3 | 480×272 |
| LQ043T3DX0A | SHARP | 4.3 | 480×272 |
| LQ043T3DX0G | SHARP | 4.3 | 480×272 |
| LR430RC9601 | Innolux | 4.3 | 480×272 |
| PT035TN01 V.6 | Innolux | 3.5 | 320×240 |
