| Varenummer | LB050WQ2-TD03 |
| Mærke | LG Display |
| Størrelse | 5.0 |
| Ansøgning | PND |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | LG.Philips LCD |
| panel model | LB050WQ2-TD03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 480×272(RGB) , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 110.736×62.424 mm |
| omrids | 124×77.2×4.7 mm |
| overflade | Antiglare |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 45 pins |
| indgangsspænding | 2.5/3.3V (Typ.)(VDD) |
| Ansøgning | PND |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| AT050TN22 V.1 | Innolux | 5.0 | 640×480 |
| AT050TN33 | Innolux | 5.0 | 480×272 |
| BB050HDG-T40 | BOE | 5.0 | 720×1280 |
| DLC0500AIG-2 | Other | 5.0 | 640×480 |
| LB050WQ2-TD03 | LG Display | 5.0 | 480×272 |
| LB050WQ3-TD04 | LG Display | 5.0 | 480×272 |
| LMS500HF05 | Samsung | 5.0 | 480×272 |
| LS050T1SX04 | SHARP | 5.0 | 1080×1920 |
| PD050VX2 | E Ink | 5.0 | 480×640 |
| 35HVF0H | SII | 3.5 | 320×480 |
| AT043TN24 V.7 | Innolux | 4.3 | 480×272 |
| AT043TN25 V.2 | Innolux | 4.3 | 480×272 |
| AT050TN33 V.1 | Innolux | 5.0 | 480×272 |
| AT050TN43 V.1 | Innolux | 5.0 | 800×480 |
| LB050WQ2-TD03 | LG Display | 5.0 | 480×272 |
| LQ036T1DG01C | SHARP | 3.6 | 272×480 |
| LQ043T3DG02 | SHARP | 4.3 | 480×272 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
| TM050NDH01 | Tianma | 5.0 | 480×272 |
