| Varenummer | LMS501KF03 |
| Mærke | Samsung |
| Størrelse | 5.0 |
| Ansøgning | MPH |
| Løsning | 480×800 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SAMSUNG SMD |
| panel model | LMS501KF03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.0 inch |
| løsning | 480(RGB)×800 , WVGA |
| visningstilstand | mPVA, Normally Black, TMR |
| aktivt område | 65.52×109.2 mm |
| omrids | 71.4×120.4×2.7 mm |
| overflade | Hard coating (3H) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1000 : 1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S2PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 51 pins |
| indgangsspænding | 1.8/3.0V (Typ.)(VDD1/VDD3) |
| Ansøgning | MPH |
