| Varenummer | DLC0220KZG |
| Mærke | Other |
| Størrelse | 2.2 |
| Ansøgning | MPH |
| Løsning | 320×320 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 120:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | DLC |
| panel model | DLC0220KZG |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.2 inch |
| løsning | 320(RGB)×320 |
| visningstilstand | ECB, Normally White, Transflective |
| aktivt område | 39.36×39.36 mm |
| omrids | 47.4×51.85×2.7 mm |
| overflade | |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 120:1 (Typ.)(Transmissive)5:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 39 pins |
| indgangsspænding | 3.0V (Typ.)(VDD) |
| Ansøgning | MPH |
