| Varenummer | LP097X02-SLQA |
| Mærke | LG Display |
| Størrelse | 9.7 |
| Ansøgning | PAD |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LP097X02-SLQA 10 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 9.7 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 196.608×147.456 mm |
| omrids | 210.35×166.25×5.45 mm |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S6PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
