| Varenummer | LP123WQ1-SPA1 |
| Mærke | LG Display |
| Størrelse | 12.3 |
| Ansøgning | Laptop |
| Løsning | 2736×1824 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 1400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| fabrikant | LG Display |
| modelnavn | LP123WQ1-SPA1 |
| skærmstørrelse | 12.3 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 2736(RGB)×1824 267PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 259.78 × 173.19 (H×V) |
| omrids (mm) | 265.38 × 183.49 × 4.25 (H×V×D) |
| rammeareal (mm) | 262.18 × 175.59 (H×V) |
| behandling | Hard coating (3H) |
| luminans | - |
| kontrastforhold | 1400 : 1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| respons | 27/46 (Max.)(Tr/Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | IPS, Normally Black, Transmissive |
| farvedybde | 16.7M |
| baggrundsbelysning | WLED , 12K hours , No Driver |
| konturform | Slim (PCBA Bent, T≤3.0mm) |
| anvendes til | Laptop |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | eDP (4 Lanes) , HBR2 (5.4G/lane) , Connector 60 pins |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -20 ~ 70 °C Operating Temp.: 0 ~ 60 °C |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LD123UX1-SMA1 | LG Display | 12.3 | 1600×1200 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01AA | TPO | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
