| Varenummer | LPM089A001A |
| Mærke | JDI |
| Størrelse | 8.9 |
| Ansøgning | PAD |
| Løsning | 2560×1600 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | JDI |
| panel model | LPM089A001A 2 Compatible model |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 8.9 inch |
| løsning | 2560(RGB)×1600 , WQXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 192×120 mm |
| omrids | 197.6×129.6×3.43 mm |
| overflade | |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S6PWLEDWithout Driver |
| signal interface | MIPI (2 ch, 4 data lanes), 61 pins |
| indgangsspænding | 1.8/3.3V (Typ.)(VDDIO/VBAT) |
| Ansøgning | PAD |
| B089AW01 V3 | AUO | 8.9 | 1024×600 |
| HT089WX1-100 | HYDIS | 8.9 | 1280×768 |
| LJ089MB2S01 | SHARP | 8.9 | 640×400 |
| LPM089A001A | JDI | 8.9 | 2560×1600 |
| LQ089B1LS11 | SHARP | 8.9 | 1280×600 |
| LT089AC29000 | TOSHIBA | 8.9 | 1280×768 |
| LTL089CL02-001 | Samsung | 8.9 | 1920×1200 |
| LTN089NT01 | Samsung | 8.9 | 1024×600 |
| N089L6-L02 | Innolux | 8.9 | 1024×600 |
| NL10260BC19-01D | NLT | 8.9 | 1024×600 |
| B080XAN03.0 | AUO | 7.9 | 768×1024 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| BP101WX1-400 | BOE | 10.1 | 1280×800 |
| HJ070IA-01I | Innolux | 7.0 | 1024×600 |
| HJ070IA-04K | Innolux | 7.0 | 800×1280 |
| HSD101PHW1-A00 | HannStar | 10.1 | 1366×768 |
| HT121WX2-211 | HYDIS | 12.1 | 1280×800 |
| HV121WX4-110 | HYDIS | 12.1 | 1280×800 |
| LP125WH2-SPT1 | LG Display | 12.5 | 1366×768 |
| N101ICG-L21 Rev.A1 | Innolux | 10.1 | 1280×800 |
