| Varenummer | LQ043T3DG01 |
| Mærke | SHARP |
| Størrelse | 4.3 |
| Ansøgning | PND |
| Løsning | 480×272 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 900:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ043T3DG01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 4.3 inch |
| løsning | 480×272(RGB) , WQVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 95.04×53.856 mm |
| omrids | 105.5×67.2 mm |
| overflade | Antiglare, Hard coating (2H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 8/21 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/60/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 9S1PWLED |
| signal interface | Parallel RGB (1 ch, 6-bit) + SPI, 67 pins |
| indgangsspænding | 3.15/3.15V (Typ.)(VDDIO/VCI) |
| Ansøgning | PND |
| LQ043T1DG01 | SHARP | 4.3 | 480×272 |
| LQ043T1DG03 | SHARP | 4.3 | 480×272 |
| LQ043T1DH41 | SHARP | 4.3 | 480×272 |
| LQ043T3DG02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX02 | SHARP | 4.3 | 480×272 |
| LQ043T3DX03A | SHARP | 4.3 | 480×272 |
| LQ043T3DX0A | SHARP | 4.3 | 480×272 |
| LQ043T3DX0G | SHARP | 4.3 | 480×272 |
| LQ043Y1DX01D | SHARP | 4.3 | 480×800 |
| LQ043Y1DX03D | SHARP | 4.3 | 480×800 |
| 35QVW1H | SII | 3.5 | 320×240 |
| 35QVW1T | SII | 3.5 | 320×240 |
| A043FW02 V0 | AUO | 4.3 | 480×272 |
| DLC0430LZG | Other | 4.3 | 480×272 |
| ED043CA-01D | Innolux | 4.3 | 480×272 |
| LB035Q02-TD01 | LG Display | 3.5 | 320×240 |
| LMS430HF18 | Samsung | 4.3 | 480×272 |
| LMS430HF27 | Samsung | 4.3 | 480×272 |
| PA040XS1 | E Ink | 4.0 | 320×234 |
| TS047NAARB01-00 | Tianma | 4.7 | 480×272 |
